Detailed introduction

◆Microcomputer control, large screen true color LCD display, full touch screen operation interface; Directly set the working program, centrifugal force, speed, centrifugal time, lifting speed, and the rotor model LCD display on the same screen

Carbon brushless AC variable frequency motor drive, using a special drive module to ensure the reliability of the circuit

◆ Double door lock system, automatically lock the door after starting, to ensure the safety of operation

◆20 kinds of work program selection, users can freely program, call its set working parameters, easy to use, improve work efficiency

◆15 kinds of acceleration /15 kinds of deceleration options, users can arbitrarily set one group of speed up and down according to sample requirements

◆ With constant speed timing (atsetrpm), start timing two functions, the point is instantaneous centrifugal (short spin) function

◆ Differential centrifugation: Reserve 5 differential centrifugation procedures, users can set their own double-layer steel structure, stainless steel centrifugal chamber, to avoid corrosive substances

◆ Automatic balance, unbalanced protection; Error or imbalance alarm signal prompts, and automatic stop

◆ parameters can be arbitrarily changed during operation, without stopping

Fastest speed up and down time ≤5s(JW-2002)

◆SOFT has soft brake function, which can effectively prevent sample resuspension and protect sensitive samples: multi-stage damping damping design to ensure sample centrifugation effect

◆ Countdown function: countdown in seconds, real-time display of remaining working time

◆ Customizable 485 communication interface, remote control [optional]

◆ Sunken exhaust channel to prevent aerosol pollution during centrifugation

Model	JW-2002 (Blood bank special)	JW-2012
Max Speed(rpm)	5000rpm	6000rpm
Max. Rcf	3130xg	5502xg
Capacity	15mlx12	15mlx12
Speed accuracy(rpm)	±10rpm
Timer range	1s~99h59min59s/ point (instantaneous) centrifugation
Test liquid temperature rise	Run for 20 minutes to test liquid temperature rise <10℃
Maximum lifting speed	≤5s	≤18s
noise	≤50dB
power supply	AC220V 50Hz 10A
power	300W
weight	28Kg
Overall dimensions [L x W x H]

Rotor configuration:

Model			JW-2022(Blood bank special)	JW-2012
Rotor	Capacity	Max rpm/RCF
NO1： Low speed angular rotor	10/15mlx12	Max Speed	5000rpm	6000rpm
		Max. Rcf	3130xg		5502xg
	adapter	choose accessories5mI
NO2： Low speed angular rotor	50mlx6	Max Speed	/	6000rpm
		Max. Rcf		5502xg
NO3： Low speed angular rotor【frozen pipe】	5mlx12	Max Speed	/	5000rpm
		Max. Rcf		2627xg
