Describe：
Model No.：HT4country of origin：ChinaWarranty period：1 YearAfter sales service：Online SupportUpdate time：2024-4-26Visits：324Product catalog
Product CategoryRelated Articles
Related ArticlesDetailed introduction
Product characteristics
This series of pumps is oil-free rotary vane vacuum pump, is a mechanical vacuum pump that can operate without any oil lubrication, it has the advantages of simple structure and easy maintenance, and will not pollute the environment.
◆ There is no oil vapor, its working environment and the treated products will not be contaminated
◆ The pump is equipped with suction filter device and exhaust noise silencer, long life, low noise, easy maintenance
◆ Overcome all kinds of industrial pollution, can ensure the clean working space
technical specification
model | HT2 | HT4 | HT8 | HT10 | HT16 | HT25 | HT40 |
pumping speed(m/h) | 2 | 7 | 8 | 10 | 16 | 25 | 40 |
limiting vacuum(mbar) | 150 | 150 | 150 | 150 | 150 | 150 | 150 |
motor power(kw) | 0.20 | 0.37 | 0.37 | 0.37 | 0.55 | 0.75 | 1.1 |
working voltage(V) | 220 | 220 | 220 | 220 | 220 | 220 | 220 |
rotate speed(r/min) | 1420 | 1420 | 1420 | 1420 | 1420 | 1420 | 1420 |
noise(dB(A)) | 56 | 60 | 60 | 60 | 61 | 62 | 67 |
boundary dimension(mm) | 248*127*157 | 246*152*186 | 266*138*169 | 317*155*190 | 230*171*198 | 494*254*289 | 560*263*289 |
weigh(KG) | 6.5 | 11.5 | 13 | 16 | 22.4 | 26 | 38.5 |
