Detailed introduction

Large screen true color LCD display screen, full touch screen operation interface; Micro computer control, brushless AC variable frequency motor drive, high speed accuracy, low noise; Programmable operation with multiple speed up and down options; Can independently set centrifugal force and speed, and display them on the same screen; With DCT (Differential Centrifuge Technology) application technology, it is widely applicable in industries such as teaching, scientific research, biochemical products, medical inspection, food safety, agricultural product testing, animal husbandry and aquatic testing, microbiology, molecular chemistry, environmental protection, quality inspection, etc.

Features of the whole machine:

◆ Micro computer control, large screen true color LCD display screen, full touch screen operation interface; Direct setting: working program, centrifugal force, speed, centrifugal time, lifting speed, and displayed on the same LCD screen as the rotor model

◆ Brushless AC variable frequency motor drive, using dedicated drive modules to ensure circuit reliability

◆ Dual door lock system, automatically locks upon startup, ensuring safe operation

◆ 20 working program options, users can freely program and call their set working parameters, making it convenient to use and improving work efficiency

◆ 15 acceleration gears/15 deceleration gears can be selected, and users can freely set one set of acceleration and deceleration gears according to sample requirements

◆ It has two functions: at set rpm and start timing, and the jog function is instantaneous centrifugation (short spin)

◆ Differential centrifugation: 5 differential centrifugation programs are reserved, and users can set them according to their needs

◆ Double layer steel structure, stainless steel centrifugal chamber, to prevent corrosive substances from corroding

◆ Automatic balancing and imbalance protection; Alarm signal prompt in case of error or imbalance, and automatic shutdown

◆ Parameters can be changed freely during operation without the need for shutdown

◆ The fastest speed up and down time is ≤ 15s [H0.512]

◆SOFT has a soft brake function, which can effectively prevent sample resuspension and protect sensitive samples; Multi stage damping and shock-absorbing design ensures the centrifugal effect of the sample

◆Countdown function: Countdown in seconds, displaying the remaining working time in real time

◆ The rotor can be sterilized under high pressure at 121 ℃ for more than 2 hours, with airtight angle rotor and high biological safety

◆ Customizable 485 communication interface for remote control [optional]

configuration：

Model	JW-3021H	JW-3022H
Max Speed	21000rpm	21000rpm
Max. Rcf	30410xg	30410xg
Max Capacity	100mlx6	750mlx4
Speed accuracy (rpm)	±10rpm
Time range	1s～99h59min59s/spot (instantaneous) centrifugation
Temperature range	Run for 20 minutes to test liquid temperature rise <10℃
Noise	≤58dB	≤58dB
Power Supply	AC220V 50Hz 10A	AC220V 50Hz 10A
Power	700W	700W
Weight	45Kg	55Kg
Overall dimensions [L x W x H]	485x370x400mm	545x430x415mm

Product consulting

Message box

Product：
Message content：
Your unit：
Your name：
Contact number：
Common mailbox：
Detailed address：
Verification Code：

JW-3021H High Speed Centrifuge
